Frame
|
Frame Birdy G3 Monocoque 7005-T6 Aluminum |
Fork New Birdy spring suspension disc brake version |
Rear Suspension 90D PU Elastomer |
Drive Train
|
Bottom Bracket Integrated |
Chainwheel Birdy TK-143-OS 52T w/double chainguard |
Chain KMC HG-40 8-speed or KMC Z83-112 |
Freewheel Sunrace CSM55-8AU 11-32T
*Gearings: 11-13-15-18-21-24-28-32 teeth*
OR
Shimano HG51 8 speed 11~30T *Gearings: 11-13-15-17-20-23-26-30 teeth*
|
Derailleur Shimano Sora 8-speed |
Shifter Shimano Revo shifter L3-SP/R8-SP |
Brakes
|
Brakes Juin Tech R1 Cable-Actuated Hydraulic Disc Brake |
Disc Rotor 6-Bolt Disc Brake Rotor 160mm |
Brake Lever TEKTRO FL-740 QR type 3-finger |
Wheels
|
Tyre Schwalbe Big Apple 18×2.0″ (50-355) |
Rim Alex Crostini M1.1 black anodized
OR
Alex DM18
|
Hub F: Birdy 32H / R: Sturmey Archer CS-RK3 3X8 32H |
Spoke Stainless steel 2.0mm (14G) |
Cockpit
|
Head Sets Semi integrated 1-1/8″ |
Handlebar Horizon AL6061T6 butted, 31.8x540mm 10D |
Stem New Birdy double lock adjustable stem 10 degree (21 degree stem is sold separately at $425) |
Seat
|
Seat Post Birdy SP-PA2 34.9mm AL7075 hard anodized w/ laser scale |
Saddle Selle SanMarco Ero Open Fit Start Up Wide
OR
Selle Italia X3
|
Accessories
|
Pedals VP-197 black cage w/BS reflectors |
Chain Tensioner PCI chain tensioner |
Bell Bell (Black) |
Optional Accessories (Kickstand, Rear Rack, Front Rack, Mudguards, etc. are Sold Separately) |
Dimensions
|
Estimated Dimensions Folded: 60cm(H) x 39cm(W) x 72cm(L) |
Rider Height 145 – 185cm |
Weight
|
Weight 12.2kg (incl. saddle & pedals) |
Max Load 110kg incl. rider & luggage |
